The M9-CCP-216 provides a 16-zone MC9 series solution for projects that require higher-capacity conventional monitoring across more areas. It is well suited to larger facilities where dependable detection zoning, robust control, and conventional system simplicity are all required. The shared MC9 family includes digital processing, two sounder channels, intelligent battery control, and repeater connection capability.
2-Year Money-Back Guarantee
Pre-Sales & Technical Support
Product Documentation Available
100% Customer Satisfaction
| Technical Specifications | |
|---|---|
| Model | M9-CCP-216 |
| Compatibility | EN 54-2, EN 54-4 |
| Power Supply | 220 V, 60/50 Hz |
| Maximum Current Consumption | 500 mA |
| Battery Type | 2×12 V, 4.5 Ah or 7.2 Ah |
| Siren Output | 2 Channels, Max 1000 mA |
| AUX Output | 24 V, 500 mA |
| Number of Zones | 16 |
| Maximum Number of Detectors Per Zone | 20 |
| Maximum Number of Zones | 24 |
| Max Fire Relay Output Current | 7 A |
| Max Fault Relay Output Current | 7 A |
| Dimensions | 405×315×85 mm |
| Weight | 3.6 kg |
Contact Atlas Pro Supply for quotation requests, product information, and project support.
